Hybrid Casement and Awning Window
Alutech Line
The Alutech casement window offers outstanding benefits. Thanks to its wider opening, it is suitable for a variety of projects, which explains its popularity in residential, commercial, and institutional buildings. Its slim frame allows plenty of natural light to enter and provides a better view of the outdoors. It is a unique window that delivers optimal energy efficiency.
Choosing the right windows is essential for absolute comfort! Windows remain a key element for a healthy home. There are several factors to consider:
- a dose of aesthetics;
- a good energy efficiency ratio;
- adequate brightness with maximum aperture;
- a source of fresh air.
- Pure white PVC profile
- Extruded aluminum on the outside, screw-connected at all four corners
- This window model has three weatherstrips, two of which are compression weatherstrips for optimum energy efficiency.
- Integrated "J" mouldings for easy interior finishing
- Sealed unit with double seal
- High-performance midsole
- Thermos Low-E Argon high energy efficiency
- Meets the requirements of NAFS-08 or CSA A440 Canadian supplement.
Our windows are designed to offer performance, durability, and energy efficiency. They are certified to NAFS-08 and CSA standards, guaranteeing excellent air, water, and wind resistance, as well as manufacturing quality that meets Canadian requirements. In addition, their Energy Star certification ensures optimal energy efficiency for increased comfort and everyday energy savings.
FRAME: PVC + Aluminium
WITH Brick Moulding
5-5/8″ (143mm)
6-3/4″ (171mm)
WITHOUT Brick Moulding
4-1/2″ (114mm)
5-5/8″ (143mm)
Select pine
PVC-coated plywood
PVC without groove
PVC with groove
Several other choices
Brick moulding
Exterior brickmould
Aluminum extrusion
without "J
"J" open
Barrotin
Aluminium tiles
Standard glazing
ClimaGuard 80/71 maximizes visible light, solar heat gain, and energy efficiency for extremely cold northern climates. With its film directly integrated into the glass, ClimaGuard 80/71 is the best choice for Quebec winters.
Standard Black Swisspacer Spacer
Manufactured in Switzerland since 1998, the Swisspacer spacer is recognized worldwide for its performance. The Ultimate model, used by Robover, is made of a highly insulating composite material that helps reduce energy loss while delivering superior performance.
Double or triple glazing
Double-pane windows (thermal windows) consist of two panes of glass separated by a layer of air or insulating gas, providing effective insulation.
Triple-pane windows add a third pane of glass and a second insulating layer, offering superior thermal and acoustic insulation.
Other lens options
- Soaked
- Laminated
- Color
- Soundproofing
Leaf configuration
Awning configuration
Shapes
Opening limiter
The SafeGard window opening controller is a reliable, easy-to-use solution that meets today's most stringent safety requirements.
Instructions for use (PDF)
Backstop
Fene-Tech manufactures windows with an interior keyguard (thermos retainer).
- Intrusion is therefore impossible without breaking the glass.
- The thermos is very easy to replace.
MultiPoint
Progressive multi-point locking system in stainless steel, with adjustable conical strike plates.
Maintenance
- Our shutters are hinged for maximum clearance, so you can clean the outside of your windows while still inside your home.
- Click here for a guide to window care (PDF)
Sash
- Triple weatherstripping, including two in high-quality neoprene for excellent frost flexibility.
- Fene-Tech's unique machining ensures perfect shutter-to-frame contact at every point, every time.
- Flexible shutter corners ensure superior sealing
Reinforcement
- With structural fabrication, the mullion separating the shutters is sealed and secured with three screws at each end.
- Steel reinforcement is inserted on all windows over 48 inches.
